Attributes
5-YearWarranty(Year)
Guangdong, ChinaPlace of Origin
0-10V (4 in 1) Series-12V24VModel Number
Pt POWERBrand Name
Led LightingApplication
PlasticCase Material
Dimming:0-10V/1-10V/10V PWM/Rx.(4 in 1)
Dimming Mode:0-10V/1-10V/10V PWM/Rx. Dimming
Efficiency:84%~99%
Energy Transfer:AC-DC
Input Voltage:100-240V/220-240V
Lighting solutions service:Lighting And Circuitry Design, Other
Output Current:0-8.33A
Output Frequency:50/60Hz
Output Power:36W-200W
Output Type:Single
Product Weight（kg）:0.37
Topology:Ac-Dc Converter
Type:IP20 Non-waterproof
Channels:1-Channel / Single Channel
IP Rate:IP20
PF:≥0.95
OEM/ODM:Yes
Working temperature:-25°C~+50°C
Type:Constant Voltage
Certification:CE/UKCA/SAA/RoHS
Other suitable application:Class 1, 2, 3 LED Lighting
Safety standard:EN61347-1,EN61347-2-13
EMC standard:55015,EN61000-3-2,EN61000-3-3
Output voltage:DC12V/24V
Unit siez(36w):264*30*18.5mm
Unit siez(75w):334*31*22.5mm
Unit siez(100w-200W):364*31*22.5mm
Weight(36w):190g
Weight(75w):330g
Weight(100w-200W):370g
Selling Units:Single item
Single package size:36.5X3.5X3 cm
Single gross weight:0.370 kg
