Attributes
±0.5 % o.r.± 1 mm/s (0.04 in/s)accuracy
liquidMedium
Ultrasonic Flow Meters, Electromagnetic Meterstype
Germanyplace of origin
/Connectivity
4 dm/min to 9600 m/h (1 gal/min to 44 000 gal/min)Flow Rate
material:Stainless Steel, Plastic
Measurement Range:4 dm/min to 9600 m/h (1 gal/min to 44 000 gal/mi
model number:Prosonic Flow P10
customized support:OEM
warranty:1 Year
Nominal Diameter Range:DN 15 to 600 (1/2 to 24")
Measuring Range:4 dm/min to 9600 m/h (1 gal/min to 44 000 gal/min)
Medium Temperature Range:-20 to +150 °C (-4 to +302 °F)
Ambient Temperature Range:-10 to +60 °C (+14 to +140 °F)
Degree Of Protection:Standard: IP66/67, Type 4X enclosure
Display/Operation:2.4" LCD display with touch & auto rotate
Outputs:4-20 mA HARTPulse/frequency/switch output Modbus RS485/4-20 mA
Measured Variables:Volume flow, conductivity, mass flow
Power Supply:DC 24 V AC 100 to 230 V AC 100 to 230 V / DC 24 V
Max. Measurement Error:±0.5 % o.r.± 1 mm/s (0.04 in/s)
