Attributes
± 0.5%accuracy
/Medium
Ultrasonic Meters, Ultrasonic Flow Meterstype
Germanyplace of origin
/Connectivity
0.5 m/s ... 5 m/sFlow Rate
material:Stainless Steel, Aluminum Alloy
Measurement Range:0.8 ~ 255000 kg/h
model number:FSS100
brand name:SIEMENS
customized support:OEM
warranty:1 Year
Accuracy:± (0.5 ... 1.5%) of flow
Repeatability:± 0.25% according to ISO 11631
Pipes Size:DN 100 ... 3000 (4" ... 120")
Line Pressure:Max. 40 bar (580 psi)
Media Temperature:-10 ... +190 °C (14 ... 374 °F); -20 ... +180 °C (-4 ... +356 °F)
Transducer Enclosure:IP67 (NEMA 6)/IP68 (NEMA 6P)
Transducer Body Materials:Stainless steel AISI 316, 200 °C (392 °F)
Dimension Of The Package Box:856 * 390 * 344 mm (33.7" * 15.4" * 13.5")
Weight Example Of A Package:Approx. 53 kg (116.8 lb)
Selling Units:Single item
