Attributes
Wire Rope HoistHoist type
12-15 MTR / MINLifting Speed
15 MTLoad Capacity
MetalMaterial
Wire RopeSling Type
16 MMwire rope diameter
Working Temperature:45 TO 50 C
Place of Origin:Gujarat, India
Power Source:Electric
Warranty:1 Year
Weight (KG):None
Brand Name:TOP CRANE SYSTEM PRIVATE LIMITED
Adjustable Travel:custom
Applicable Industries:Building Material Shops, Manufacturing Plant, Construction works , Energy & Mining, Other
Condition:New
Control Mode:Remote Control
Length:16 MM
Machinery Test Report:Provided
Motor Power:10 kW
Operation Type:Remote Control
Protection Rating:IP55, IP66, IP65, IP54
Voltage:440 V
Standard:IS 3177 / IS 807
Class & Duty:CLASS 2 HEAVY DUTY
Hoisting Speed:3.5 TO 4 MTR/MIN +/- 10 % with VFD FOR SLOW SPEED
Hoisting Motor:15 HP 1440 SQ. CAGE ,S4 DUTY,40 % CDF , F CLASS INSULATION
Hoisting Brake:THRUSTER BRAKE
C.T Speed Rating:2 HP 1440 RPM SQ. CAGE , 40 % CDF F-CLASS INSULATION
No Of Falls:4 FALL
Hook:IS 8610/ IS 3815, SWIVELING HOOK WITH SAFETY LATCH
Bearing:BALL BEARING TYPE
BUFFER:RUBBER TYPE
Wheel Assembly:2 DRIVEN 2 DRIVER
Panel Enclosure:IP55 (DUST AND MOISTURE PROOF ENCLOSURE)
