Attributes
1600*6000Working Table Size(mm)
CNC Routermachine type
CNCcnc or not
Shandong, Chinaplace of origin
380V/220Vvoltage
11Power (kW)
weight (kg):3500
warranty:1 Year
range of spindle speed(r.p.m):0 - 24000 rpm
positioning accuracy (mm):0.03 mm
number of axes:4
No. of Spindles:Multi
travel (x axis)(mm):1600 mm
travel (y axis)(mm):6000 mm
repeatability (x/y/z) (mm):0.03 mm
Spindle Motor Power (kw):14
brand name:Blue Elephant
dimension(l*w*h):Other
key selling points:Multifunctional
machinery test report:Provided
video outgoing-inspection:Provided
core components:Motor, PLC
Model:ELECNC1660-3S
Inverter type:5.5KW
Command language:G Code & M Code
Traveling speed:80m/min
Working speed:0-25m/min
System resolution:±0.0025mm
Re-positioning accuracy:±0.03mm
Working accuracy:±0.03mm
Working air pressure:0.6MPa
Working voltage:220V 1PH/3PH 50HZ/60HZ 380V 3PH 50HZ/ 60HZ
Selling Units:Single item
