Attributes
380 V, 220V Electrical Equipmentvoltage
FANUCcnc control system
Light Dutymachining capacity
6number of axes
2no. of spindles
12tool post stations
max. length of workpiece (mm):200
key selling points:Multifunctional, Automatic, Competitive Price, High-Accuracy
repeatability (x/y/z) (mm):±0.005
positioning accuracy (mm):±0.005
warranty:1 Year
type:cnc lathe
machinery test report:Provided
video outgoing-inspection:Provided
max. weight of workpiece(kg):50
travel (x axis)(mm):100
travel (z axis)(mm):100
place of origin:Guangdong, China
dimension(l*w*h):2100x1100x1700
brand name:HANSUN
model number:20Z-DY
weight:2880
range of spindle speed:0 - 8000
single feed travel:80mm
main spindle max RPM:8000
main spindle max turning diameter:20mm
main spindle additional positive brake:stepless
spindle bore:22mm
sub-spindle max RPM:8000rpm
number of O.D tools:5
O.D tool size:12x12
number of front work tools:4
max drilling diameter(front):8mm
max tapping diameter(front):M8
number of cross driven tools:4
max drilling diameter(cross):8mm
max tapping diameter(cross):M6
max blade diameter ofr side milling:32mm
end face drilling fixed tool holder:4xER11
main spindle motor:3.7/2.2kw
rapid traverse rate:25m/min
