Attributes
380 VVoltage
12.8kwPower(W)
Wood, AluminumApplicable Material
Guangdong, ChinaPlace of Origin
Gearbox, Bearing, EngineCore Components
1200 kgWeight
Warranty:1 Year
Key Selling Points:High-Accuracy
Video outgoing-inspection:Provided
Machinery Test Report:Provided
Brand Name:ZLWM
Dimension(L*W*H):4700*1340*2300mm
Transformer Specification:2.8kW (380V 50Hz)
Air Source:0.6-0.8 MPa
Ball Screw Lubrication:Automatic guideway oil lubrication
Linear Guide Lubrication:Automatic guideway oil lubrication
Cutting Cooling:Spray type
Chip Removal:Discharge water tank with chip bucket
Machine Protection:Chip guard plate
Guide Rail Protection:Accordion cover
Max Clamping Range:3000 * 100 * 50 mm (L * W * H)
X-Axis Travel:3000 mm
Y-Axis Travel:200 mm
Z-Axis Travel:100 mm
Overall Dimensions (L * W * H):4410 * 2070 * 2065 mm
Machine Weight:approx 1200 kg
Power Requirement:12.8 kW, 4² cable, 380V 50Hz
Ambient Temperature (24h average ≤35°C):5-40°C
Relative Humidity:30-75%
Vibration Intensity:<0.5 kg
Ground Resistance:<10 Ω (independent grounding, not shared)
