3000W Compact Structure Side Mounted Fiber Laser Tube Cutter 700kg Load Capacity for Large Diameter Steel Pipe Side Mounted Desi

Name: 3000w Compact Structure Side Mounted Fiber Laser Tube Cutter 700kg Load Capacity For Large Diameter Steel Pipe Side Mounted Desi - Buy Product on Alibaba.com
Brand: CONG TY TNHH VINFINITE RESOURCES
SKU: 1601863800152
Price: 16350 USD
Availability: InStock

No reviews yet

£12,76748

1-4 sets

£12,37027

≥5 sets

Select now

cutting area

6500 mm*360 mm(255.91in*14.17in)

Laser Source Brand

JPT

model number

LM-6035T2S

+ 1 more variants

Key attributes

Applicable Material

Stainless Steel, Copper, Carbon Steel, Aluminum, Galvanized Pipe, Alloy Steel, Titanium Alloy

laser type

Fiber Laser

cnc or not

Yes

Laser Power

3000 W

cutting thickness

Carbon Steel 1-12 mm, Stainless Steel 1-8 mm, Aluminum 1-6 mm, Copper 1-3 mm

products handled

Large Diameter Metal Pipes Tubes Processing

Shipping

Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.

Alibaba.com order protection

Secure payments

Every payment you make on Alibaba.com is secured with strict SSL encryption and PCI DSS data protection protocols

Money-back protection

Claim a refund if your order doesn't ship, is missing, or arrives with product issues

Only orders placed and paid through Alibaba.com can enjoy free protection by

Key attributes

Applicable Material

Stainless Steel, Copper, Carbon Steel, Aluminum, Galvanized Pipe, Alloy Steel, Titanium Alloy

laser type

Fiber Laser

cnc or not

Yes

Laser Power

3000 W

cutting thickness

Carbon Steel 1-12 mm, Stainless Steel 1-8 mm, Aluminum 1-6 mm, Copper 1-3 mm

products handled

Large Diameter Metal Pipes Tubes Processing

control system brand

Beckhoff TwinCAT Control

configuration

Dual Chuck Heavy Duty Side Hanging System

Cutting Speed

Up to 100 m/min, Up to 100 m min

Feature

Large Tube Capacity High Power Cutting

Key Selling Points

Mounted Design Frame Above Completely Open Space B, Two Chuck Design Stable Clamping Auto Centering, Round Pipe 14-360 mm Square Pipe 14-355 mm Covers

guiderail brand

INA Precision Linear Guide

servo motor brand

Autonics

laser head brand

Raytools(the other brand can be choose)

cooling mode

Water-Cooling

Control Software

Dual Chuck Side Hanging System

graphic format supported

AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT

warranty

2 Years

condition

New

mode of operation

Continuous Wave Operation

optical lens brand

II-VI

place of origin

Shandong, China

AI Cutting Optimization

Smart Nesting, Pierce Parameter Optimization, Anti-Collision Detection, Basic Cutting

brand name

Laser Max

Weight

7800

Function

12500 mm

Applicable Tube Diameter

Round 14 360mm Square 355mm

Max Tube Weight

700 KG

Chuck Rotation Speed

60 r min

Cutting Thickness

Carbon Steel 10mm Stainless Steel 5mm

Cutting Accuracy

0.08 mm High Precision

Chuck System Type

Dual Chuck Heavy Duty Side Hanging

Bevel Cutting Range

0 45 Degrees Full Bevel

Hole Cutting Size

Up to 200mm Diameter Holes

Packaging and delivery

Selling Units

Single item

Single package size

850X250X200 cm

Single gross weight

7800.000 kg
