Attributes
5-YearWarranty(Year)
Guangdong, ChinaPlace of Origin
PV-12060H-M1A / PV-24060H-M1AModel Number
Pt POWERBrand Name
Led Lighting, Outdoor Lighting, Street LightApplication
AluminumCase Material
Dimming:None
Dimming Mode:Non-dimmable
Efficiency:≥89%
Energy Transfer:AC-DC
Input Voltage:AC170-264V
Lighting solutions service:Lighting And Circuitry Design, Project Installation, Other
Output Current:2.5A/5A
Output Frequency:50~60Hz
Output Power:60W
Output Type:Single
Product Weight（kg）:0.43
Topology:Ac-Dc Converter
Type:IP67 Waterproof
Type:Constant Voltage LED Driver
Output Volt.:DC12V/24V
Working temperature:-25°C~+60°C
Certification:CE/CB/SAA/RoHS
Size:292*37*22mm
PF:≥0.95
IP Rate:IP67
OEM:Yes
ODM:Yes
Standby power consumption:<0.5W
EMC Standard:EN55015,EN61000-3-2,EN61000-3-3
Safety standard:EN61347-1,EN61347-2-13
Protection:Short circuit, overload protection
