Attributes
LED video walluse
3.906mmPixels
LedScreen Type
Original Manufacturer, ODM, OEMsupplier type
Othermedia available
2 Yearswarranty
application:Indoor
aspect ratio:16:9, Other
place of origin:Guangdong, China
brightness:800~1000 Nits
Remote Device Management:No
specification:LED cabinet
model number:Air3.9 Lite Flx
brand name:Aistartech
color:Full Color
Color Depth:14~16 bit
Dimensions:500x500x72mm
function:SDK
installation type:Hanging Stacking
ip rating:IP 30 / IP30
Material:Die Casting Aluminum
Operating Temperature:-20°C To 50°C
Pixel Pitch:P3.9
Usage environment:Indoor
view angle（h/v）:140/140, 160°, 140°
Voltage:100-110 V / 200-240 50-60 Hz
LED:SMD2020
Pixel per Panel(WxH):128x128/128x256mm
Weight:7.6 Kg/Panel/11.6Kg/Pane
Processing:14~16 bit
Refresh Rate:≥7680 Hz
Driving Type:1/16
Signal Transmission:<100 m(CAT5) 100m-500m (Multimode ) 500m-10km (Single mode)
Max Power Consumption:800w/Sq.m
Average Power Consumption:440w/Sq.m
Recommended Application:Rental
Humidity:10%-90% (operational) 10%-90% (storage)
Input Voltage Frequency:100-240V 50-60 Hz
