Attributes
VERTICALtype
750table travel (x) (mm)
290table travel (y) (mm)
450table travel (z) (mm)
Customer Requirementvoltage
BT40spindle taper
machining capacity:Medium Duty
range of spindle speed(r.p.m):60 - 1800 r.p.m
place of origin:Canada
weight (kg):2350
warranty:1 Year
max. table load(kg):300 kg
brand name:SMAC
model number:XL6336
dimension(l*w*h):2520*2100*2500
key selling points:Energy Saving
machinery test report:Provided
video outgoing-inspection:Provided
Table feed. (X, Y, Z):30~750mm/min
Spindle taper:7:24 IS050 (H)
Spindle travel:127mm
T-slots(NO:/width/pitch):3/18/70mm
Arm travel:550mm
3 to feed Ac servo motor torque:10N.m
Machine Type:Veritcal
Function:Metal Milling
Precision:High
Processing:Mechanical Processing
