Attributes
Generalapplication
-50°C ~ 100°C, 0°C ~ 400°COperating Temp. Range
375-725 psi, 0-1 MPaOperational Pressure Range
1/4 inport size
Pneumaticpower
Valve typestructure
customized support:OEM
place of origin:Shanghai, China
model number:Azbil HLC HTS
brand name:Azbil
media:Gas
temperature of media:High Temperature, Low Temperature, Medium Temperature, Normal Temperature
warranty:1 year
Valve type:Small-port single-seat control valve
Size:1/2 in-1 in
Pressure rating:JIS10K-30K ANSI (JPI) 150 to 600
End connection:Flange: RF, FF
Body material:SCPH2 SCS13A
Inherent Characteristics:Linear
Trim material:SUS316, SUS316 + CoCr-A hardfacing SUS316 + PTFE with carbon fiber
Temperature range:-196 to + 566 ° C
Leakage performance:Classes IV, VI
Cv range:0.4 to 100
