Attributes
CNC Routermachine type
1500*3000Working Table Size(mm)
4number of axes
MultiNo. of Spindles
380V/220Vvoltage
1 Yearwarranty
cnc or not:CNC
place of origin:Shandong, China
Power (kW):11
weight (kg):3500
range of spindle speed(r.p.m):0 - 24000 rpm
positioning accuracy (mm):0.03
travel (x axis)(mm):1500
travel (y axis)(mm):3000
repeatability (x/y/z) (mm):0.03
Spindle Motor Power (kw):3.7
brand name:Blue Elephant
dimension(l*w*h):Other
key selling points:Multifunctional
machinery test report:Provided
video outgoing-inspection:Provided
core components:Motor, PLC
Model:ELECNC1530
Command language:G Code & M Code
Traveling speed:0m/min8
Working speed:0-25m/min
Re-positioning accuracy:±0.03mm
System resolution:±0.0025mm
Working accuracy:±0.0mm3
Working air pressure:0.6MPa
Working voltage:220V 1PH/3PH 50HZ/60HZ 380V 3PH 50HZ/ 60HZ
Inverter type:3.7kw
