Common Mode Choke Low Frequency High Saturation Low DCR Axial Copper Winding Automotive Power High Current CE Certified RoHS

No reviews yet
£230
Minimum order quantity: 10 pieces
Specification
Customization options
Customized logo (Min. order: 1,000 pieces)
Customized packaging (Min. order: 1,000 pieces)
Graphic customization (Min. order: 1,000 pieces)

Key attributes

Model Number

BPXQ-29

Type

Edgewise Winding / Flat-wise Winding Inductor

Brand Name

Speed

Application

High-power Inverters / EV Charging Piles

Rated Power

100W - 5000W (Size dependent)

Mounting Type

Bolt-on / Custom Solder Leads

Shipping
Select shipping

Alibaba.com order protection

Secure payments

Every payment you make on Alibaba.com is secured with strict SSL encryption and PCI DSS data protection protocols

Money-back protection

Claim a refund if your order doesn't ship, is missing, or arrives with product issues

Only orders placed and paid through Alibaba.com can enjoy free protection by

Key attributes

Model Number
BPXQ-29
Type
Edgewise Winding / Flat-wise Winding Inductor
Brand Name
Speed
Application
High-power Inverters / EV Charging Piles
Rated Power
100W - 5000W (Size dependent)
Mounting Type
Bolt-on / Custom Solder Leads
Place of Origin
Guangdong, China
Mfg. Date Code
20260101-20561230
Brand
Speed / OEM / ODM
Supplier Type
Manufacturer Direct Supply
Cross Reference
Custom-made Parts
Tolerance
Inductance Tolerance 5% or 10%
Operating Temperature
-40c to +180c (Class H)
Package Type
Open-frame Custom Packaging
Resistance Tolerance
Resistance Error 5%
Temperature Coefficient
3930 ppm/K (Pure Copper)
Resistance
0.2m - 5.0m(DCR) / Frequency Dependent
Media Available
Datasheet / Drawings / RoHS
Frequency - Self Resonant
Self-resonant Frequency (SRF) 1 MHz
Features
High Current/ Ultra-low DCR/ High Heat Dissipation
Height - Seated (max)
Customized / 10-50mm (Turns dependent)
Function
HF Filtering / Resonance / Energy Storage
Inductance
Customized / 1H - 100H
Q @ Freq
High Q-factor: 80
Package / Case
Bare Coil / Varnish Impregnated
Size / Dimension
Outer Diameter: 20mm - 120mm
Height
Customized / 5mm - 100mm
Number of Coils
Customized / 3T - 200T
Inductance - Connected In Parallel
Customized / 1H - 100H
Inductance - Connected In Series
Customized / 1H - 100H
Current Rating - Parallel
Customized / 20A - 200A
Current Saturation - Parallel
No Saturation (Air core does not saturate)
Current Saturation - Series
No Saturation (Air core does not saturate)
DC Resistance (DCR) - Parallel
0.2m - 5.0m
DC Resistance (DCR) - Series
0.2m - 5.0m
Shielding
Non-shielded
Material - Core
None / Ferrite / Mn-Zn / Ni-Zn / Sendust (Kool Mu)
Current Rating (amps)
20A - 200A
Current - Saturation
20A - 200A
DC Resistance (DCR)
0.2m - 5.0m

Packaging and delivery

Selling Units
Single item
Single package size
30X20X10 cm
Single gross weight
0.500 kg

Lead time

Customization options

Customized logo(+ from /Min. order: 1,000 pieces)
