Desktop Small Cnc Router 3018PLUS 2.0 Version 3018PRO MAX 775W Spindle for Wood Cutting
No reviews yet
Attributes
3number of axes
110 V, 220Vvoltage
CNC Routermachine type
SingleNo. of Spindles
Easy To Operatekey selling points
spindle motorAccessory Type
core components:Motor, Aluminum frame, Mother controller
warranty:1 Year
cnc or not:CNC
video outgoing-inspection:Provided
machinery test report:Provided
place of origin:Jiangsu, China
weight (kg):7.5
range of spindle speed(r.p.m):1 - 8000
positioning accuracy (mm):0.05
travel (x axis)(mm):300
travel (y axis)(mm):180
repeatability (x/y/z) (mm):0.05
Spindle Motor Power (kw):0.1
brand name:Zhong Hua Jiang
dimension(l*w*h):440*250*180mm
Max.stroke:300*180*40mm
Outline Dimension:440*250*180mm
Rail Type:Chrome Plated Shaft+Linear Bearing
Mechnical Resolution:XYZ-shift: 0.005mm/step
Machinable Material Thickness:45mm
Frame Material:Aluminium Alloy
Screw Type:T Type screw, Diameter 8mm, Thread Pitch 2mm
Positioning Accuracy:0.05mm
Spindle Motor:775 Spindle Motor 12-24V
RPM:8000rpm/min
Key attributes
number of axes
3
voltage
110 V, 220V
machine type
CNC Router
No. of Spindles
Single
key selling points
Easy To Operate
Accessory Type
spindle motor
core components
Motor, Aluminum frame, Mother controller
warranty
1 Year
cnc or not
CNC
video outgoing-inspection
Provided
machinery test report
Provided
place of origin
Jiangsu, China
weight (kg)
7.5
range of spindle speed(r.p.m)
1 - 8000
positioning accuracy (mm)
0.05
travel (x axis)(mm)
300
travel (y axis)(mm)
180
repeatability (x/y/z) (mm)
0.05
Spindle Motor Power (kw)
0.1
brand name
Zhong Hua Jiang
dimension(l*w*h)
440*250*180mm(17.32*9.84*7.09in)
Max.stroke
300*180*40mm
Outline Dimension
440*250*180mm
Rail Type
Chrome Plated Shaft+Linear Bearing
Mechnical Resolution
XYZ-shift: 0.005mm/step
Machinable Material Thickness
45mm
Frame Material
Aluminium Alloy
Screw Type
T Type screw, Diameter 8mm, Thread Pitch 2mm
Positioning Accuracy
0.05mm
Spindle Motor
775 Spindle Motor 12-24V
RPM
8000rpm/min
Packaging and delivery
Selling Units
Single item
Lead time
Customization options
Customized logo(+ from /Min. order: 50 sets)
Customized packaging(+ from /Min. order: 50 sets)
Graphic customization(+ from /Min. order: 50 sets)
View details
Product descriptions from the supplier
Warning/Disclaimer
California Proposition 65 Consumer WarningView more
Customizable
1 - 9 sets
£132.00
>= 10 sets
£12823
Variations
Select nowWorking Table Size(mm): XYZ=300*180*40mm
XYZ=300*180*40mm
model number: 3018
3018
Power (kW)
0.1 kW(0.13hp)
Customization options
Customized logo (Min. order: 50 sets)
Customized packaging (Min. order: 50 sets)
Graphic customization (Min. order: 50 sets)
