Attributes
CNC Routermachine type
1300*1300Working Table Size(mm)
othernumber of axes
ATCNo. of Spindles
380V/220Vvoltage
1 Yearwarranty
cnc or not:CNC
place of origin:Shandong, China
Power (kW):7.5
weight (kg):2000
range of spindle speed(r.p.m):0 - 24000 rpm
positioning accuracy (mm):0.03 mm
travel (x axis)(mm):1300 mm
travel (y axis)(mm):1300 mm
repeatability (x/y/z) (mm):0.03 mm
Spindle Motor Power (kw):6
brand name:Blue Elephant
dimension(l*w*h):OTHER
key selling points:Multifunctional
machinery test report:Provided
video outgoing-inspection:Provided
core components:Motor, PLC
Model:ELECNC1313
Linear guide:Taiwan linear guide
Command language:G Code & M code
Traveling speed:30m/min
Working speed:0-25m/min
Re-positioning accuracy:±0.03mm
Compatible software:Artcam / Aspire, etc
Working accuracy:±0.05mm
System resolution:±0.0025mm
Working voltage:220V 1PH/3PH 50HZ/60HZ 380V 3PH 50HZ/60HZ
