Edm Discharge High Precision Electrode Chuck with High Repeatable Positioning Accuracy.it Can Be Directly Connected to Chuckner
No reviews yet
Attributes
Wire EDMmachine type
380 V, 220V Electrical Equipment, 110 Vvoltage
CNCcnc or not
Providedmachinery test report
High Productivitykey selling points
Providedvideo outgoing-inspection
core components:PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear
warranty:1 Year
power (kw):6
place of origin:Jiangsu, China
weight (kg):2500
brand name:Minnuo
dimension(l*w*h):2050*1720*2160
Product name:Edm Machine ≤0.008mm Level Precision
Precision:≤0.008mm
Certification:CE ISO
Max - machining speed:≥250mm/min
Power supply:Three-phase 3N-380V/50Hz
Average cutting efficiency:70mm²/min
Surface roughness (straight line):First cut Ra < 2.5μm, third cut Ra < 0.8μm, fourth cut Ra < 0.6μm
Wire feed rate:1 - 11.4/8 segments, frequency - adjustable
Control and connection mode:X,Y,U,Vstepping (gear)/hybrid,servo (direct-drive) drive
noise:≤70db
Key attributes
machine type
Wire EDM
voltage
380 V, 220V Electrical Equipment, 110 V
cnc or not
CNC
machinery test report
Provided
key selling points
High Productivity
video outgoing-inspection
Provided
core components
PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear
warranty
1 Year
power (kw)
6
place of origin
Jiangsu, China
weight (kg)
2500
brand name
Minnuo
dimension(l*w*h)
2050*1720*2160
Product name
Edm Machine ≤0.008mm Level Precision
Precision
≤0.008mm
Certification
CE ISO
Max - machining speed
≥250mm/min
Power supply
Three-phase 3N-380V/50Hz
Average cutting efficiency
70mm²/min
Surface roughness (straight line)
First cut Ra < 2.5μm, third cut Ra < 0.8μm, fourth cut Ra < 0.6μm
Wire feed rate
1 - 11.4/8 segments, frequency - adjustable
Control and connection mode
X,Y,U,Vstepping (gear)/hybrid,servo (direct-drive) drive
noise
≤70db
Packaging and delivery
Selling Units
Single item
Single package size
XX cm
Lead time
Product descriptions from the supplier
Minimum order quantity: 1 piece
£5,96870
Variations
Select nowmodel number
MNH-7740
Shipping
Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.
