Fine Pixel Pitch SMD2020 LED Video Wall Display Panel 3.9mm Indoor Rental 500x1000mm Size 7680Hz Refresh Rate Digital Signage
No reviews yet
Attributes
LED cabinetspecification
IndoorUsage environment
P3.9Pixel Pitch
800~1000 Nitsbrightness
IP 30 / IP30ip rating
500x500x72mmDimensions
application:Indoor
aspect ratio:16:9, Other
Screen Type:LED Display Screen
warranty:2 Years
place of origin:Guangdong, China
Remote Device Management:No
use:LED video wall
model number:Air3.9 MAX
brand name:Aistartech
color:Full Color
Color Depth:16-Bit
Control Method:App Control
function:SDK
installation type:Hanging Stacking
Material:Die Casting Aluminum
media available:Other
Operating Temperature:-20°C To 50°C
Pixel Density:65536Pixel/sqm
Pixels:3.906mm
supplier type:Original Manufacturer, ODM, OEM
view angle（h/v）:140/140, 160°, 140°
Voltage:100-110 V / 200-240 50-60 Hz
LED:SMD2020
Pixel per Panel(WxH):128x128/128x256mm
Weight:7.0 Kg/Panel/11.7kg/panel
Processing:14~16 bit
Refresh Rate:≥7680 Hz
Driving Type:1/21
Signal Transmission:<100 m(CAT5) 100m-500m (Multimode ) 500m-10km (Single mode)
Max Power Consumption:480w/Sq.m
Average Power Consumption:280w/Sq.m
Recommended Application:Rental
Humidity:10%-90% (operational) 10%-90% (storage)
Input Voltage Frequency:100-240V 50-60 Hz
Key attributes
specification
LED cabinet
Usage environment
Indoor
Pixel Pitch
P3.9
brightness
800~1000 Nits
ip rating
IP 30 / IP30
Dimensions
500x500x72mm
Remote Device Management
No
Control Method
App Control
aspect ratio
16:9, Other
Operating Temperature
-20°C To 50°C
Color Depth
16-Bit
Voltage
100-110 V / 200-240 50-60 Hz
Material
Die Casting Aluminum
warranty
2 Years
function
SDK
Screen Type
LED Display Screen
use
LED video wall
application
Indoor
Pixels
3.906mm
view angle（h/v）
140/140, 160°, 140°
Pixel Density
65536Pixel/sqm
media available
Other
supplier type
Original Manufacturer, ODM, OEM
place of origin
Guangdong, China
model number
Air3.9 MAX
brand name
Aistartech
color
Full Color
installation type
Hanging Stacking
LED
SMD2020
Pixel per Panel(WxH)
128x128/128x256mm
Weight
7.0 Kg/Panel/11.7kg/panel
Processing
14~16 bit
Refresh Rate
≥7680 Hz
Driving Type
1/21
Signal Transmission
<100 m(CAT5) 100m-500m (Multimode ) 500m-10km (Single mode)
Max Power Consumption
480w/Sq.m
Average Power Consumption
280w/Sq.m
Recommended Application
Rental
Humidity
10%-90% (operational) 10%-90% (storage)
Input Voltage Frequency
100-240V 50-60 Hz
Packaging and delivery
Selling Units
Single item
Lead time
Product descriptions from the supplier
1 - 399 pieces
£11961
400 - 1,599 pieces
£11510
≥ 1,600 pieces
£10908
Variations
Select nowscreen size
500x500mm(19.69x19.69in)
500x1000mm(19.69x39.37in)
Shipping
Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.
