Attributes
Three PhaseOutput Type
99.0%Inverter Efficiency
Zhejiang, ChinaPlace of Origin
GT 100kw-125kw SeriesModel Number
GoodweBrand Name
1100VInput Voltage
Output Voltage:220/380V, 230/400V
Output Current:167.1-199.4A
Output Frequency:50Hz/60Hz
Size:930*650*300 mm
Type:DC/AC Inverters
Weight:88kg
MPPT Operating Voltage Range (V):180 ~ 1000
Start-up Voltage (V):200
Nominal Input Voltage (V):600
Max. Input Current per MPPT (A):42
Max. Short Circuit Current per MPPT (A):52.5
Operatin Temperature Range (°C):-30 ~ +60
Cooling Method:Smart Fan Cooling
User Interface:LED, LCD (Optional), WLAN + APP
Communication:RS485, WiFi + LAN or 4G or PLC (Optional)
Ingress Protection Rating:IP66
