Attributes
Three PhaseOutput Type
97.9%Inverter Efficiency
Zhejiang, ChinaPlace of Origin
MS G4 7.5-10kw SeriesModel Number
GoodweBrand Name
40 ~ 560VInput Voltage
Output Voltage:220 / 230 / 240V
Output Current:34.1-36.4A
Output Frequency:50Hz/60Hz
Size:493*365*187 mm
Type:DC/AC Inverters
Weight:16kg
Max. Input Voltage (V):600
MPPT Operating Voltage Range (V):40 ~ 560
Start-up Voltage (V):50
Nominal Input Voltage (V):360
Max. Input Current per MPPT (A):20
Max. Short Circuit Current per MPPT (A):26
User Interface:LED, LCD (Optional), WLAN + APP
Communication:RS485, WIFI, LAN, Bluetooth, 4G
Communication Protocols:Modbus-RTU (SunSpec Compliant)
Ingress Protection Rating:IP66
Selling Units:Single item
