Attributes
380 VVoltage
2.5KWPower(W)
Wood, AluminumApplicable Material
Guangdong, ChinaPlace of Origin
Gearbox, Bearing, MotorCore Components
500 kgWeight
Warranty:1 Year
Key Selling Points:High Productivity
Video outgoing-inspection:Provided
Machinery Test Report:Provided
Brand Name:ZLWM
Dimension(L*W*H):3485x2570x1190(mm)
Input Power:380V 220V 50Hz
Working Air Pressure:0.4-0.8MPa
Total Power:2.5KW
Spindle Power:2.2KW
Blade Speed:5000rpm
Blade Specification:305*25.4*3.0*120T
Cutting Height:50mm
Max Cutting Stroke:2500mm
Cutting Direction:Right to left
Cutting Length Accuracy:±0.3mm
Angle Accuracy:10-30
Raw Material Max Length:2500mm
Cutting Length Range:500mm
Blade Cutting Speed:0-5m/min
Machine Size L*W*H:3485*2570*1190mm
Total Weight:500KG
Working Environment Requirements:Power cable 2.5² 380V 50Hz
Temperature:5-40°C
Relative humidity:30-75 percent
Ground resistance:less than 10Ω independent grounding
