Attributes
Horizontaltype
CNCcnc or not
380 V, 220 V, 420Vvoltage
5number of axes
55kwspindle motor power(kw)
6150*3100table size (mm)
Automatic Grade:Automatic
no. of spindles:Single
key selling points:Energy Saving
core components:PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump
warranty:2 Years
machinery test report:Provided
video outgoing-inspection:Provided
table travel (x) (mm):6000
table travel (y) (mm):3000
table travel (z) (mm):1200
range of spindle speed(r.p.m):8000
place of origin:Jiangsu, China
weight (t):48
max. table load(kg):20000
travel (w-axis) (mm):1200
positioning accuracy (x axis) mm:0.012
positioning accuracy (y axis) mm:0.012
positioning accuracy (z axis) mm:0.012
production capacity:500
brand name:MINNUO
dimension(l*w*h):6800x5500x6400
Product name:High Lifespan MNTK6916 Vertical Boring Machine Automated Production
Spindle Diameter(mm):160
Electrical Total Capacity(Approx.)(KVA):87
Movement Speed(mm):1-8000
Distance to Worktable Surface(mm):30-1530
Maximum Spindle Thrust(N):18000
Spindle Nose Diameter(mm):220
Spindle Taper Hole:BT50
Application:Construction Machine Repairing
After-sales Service Provided:Engineers
