High Production Fully Injection Molding Machine for Chair Making Processes HDPE PPR PVC PET ABS EVA PP/ Chair Mold

No reviews yet
£84,51196
1-2 sets
£79,22996
≥3 sets
Select now

clamping force

8500 KN
Customization options
Customized logo (Min. order: 3 sets)
Customized packaging (Min. order: 3 sets)
Graphic customization (Min. order: 3 sets)

Key attributes

machine type

Hydraulic

style

Horizontal

distance between tie bars

1016X980 mm

plastic processed

PP, PC, ABS, PET, PVC, FRPP/PVC, PPR, EVA, HDPE, MLLDPE, EPS, PA, Polystyrene, PE, LDPE, EVOH, HDPE/PP, ABS/PP, PE/PP, Polylactic Acid, PS

key selling points

Automatic

core components

Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Engine, Gearbox, Screw, Other

Shipping

Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.

Alibaba.com order protection

Secure payments

Every payment you make on Alibaba.com is secured with strict SSL encryption and PCI DSS data protection protocols

Money-back protection

Claim a refund if your order doesn't ship, is missing, or arrives with product issues

Only orders placed and paid through Alibaba.com can enjoy free protection by

Key attributes

machine type
Hydraulic
distance between tie bars
1016X980 mm
plastic processed
PP, PC, ABS, PET, PVC, FRPP/PVC, PPR, EVA, HDPE, MLLDPE, EPS, PA, Polystyrene, PE, LDPE, EVOH, HDPE/PP, ABS/PP, PE/PP, Polylactic Acid, PS
style
Horizontal
key selling points
Automatic
ejector number
21
core components
Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Engine, Gearbox, Screw, Other
warranty
1 Year
machinery test report
Provided
video outgoing-inspection
Provided
Raw Material
Polyethylene (Pe), Polypropylene (PP), Polyvinyl Chloride (PVC), Polyester (PET)
plasticizing capacity(g/s)
910
injection weight (g)
4350
injection rate (g/s)
840
weight (kg)
45000
place of origin
Guangdong, China
power (kw)
74
mold height(mm)
320 - 750
ejector stroke(mm)
260
ejector force(kn)
186
theoretical shot volume(cm³)
4840
screw speed (rpm)
0 - 160
screw diameter (mm)
108
Screw L/D Ratio
20.4
open stroke(mm)
980
model number
BST-8500A
brand name
BEST Machinery
Product name
High Quality Automatic Plastic Chair Making Injection Molding Machine
Injection pressure
141 Mpa
Mould thickness
400-960 mm
Ejector tonnage
186KN
Ejector number
21 Pieces
Hole diameter
250mm
Max pump pressure
16 Mpa
Machine dimension
11*2.4*2.75 m
Machine weight
45 t
Oil tank capacity
1300 L

Packaging and delivery

Selling Units
Single item
Single package size
1100X240X275 cm
Single gross weight
45000.000 kg

Lead time

Customization options

Customized logo(+ from /Min. order: 3 sets)
Customized packaging(+ from /Min. order: 3 sets)
Graphic customization(+ from /Min. order: 3 sets)
