High Torque Planetary Gearbox 60PF Model Ratio 10 Nema 23 Stepper Motor Flange Mounted Automated Packaging Line Robotic Arms
No reviews yet
Attributes
Depending on the motorOutput Torque
10:1Ratio
-Maximum Input Horsepower
PlanetaryGear Type
Flanged ShaftOutput Shaft Type
Flange MountedMounting Orientation
Gearing Arrangement:Planetary
Output Speed:Depending on the motor
Applicable Industries:Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Energy & Mining
Place of Origin:Jiangsu, China
Input Speed:Depending on the motor
Warranty:1 Year
Weight (KG):1.1
Model:60PF10
Noise (L=100cm):≤70dB
Emergency Stop Torque (N.m):2 times the rated output torque
Allowable Radial Load:680N
Allowable Axial Load:340N
Rated Input Speed:1000rpm
Maximum Input Speed:2000rpm
Protection Level IP:IP65
Applied Motor:Nema 23 Stepper Motor
Key attributes
Output Torque
Depending on the motor
Ratio
10:1
Maximum Input Horsepower
-
Gear Type
Planetary
Output Shaft Type
Flanged Shaft
Mounting Orientation
Flange Mounted
Gearing Arrangement
Planetary
Applicable Industries
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Energy & Mining
Warranty
1 Year
Input Speed
Depending on the motor
Output Speed
Depending on the motor
Place of Origin
Jiangsu, China
Weight (KG)
1.1
Model
60PF10
Noise (L=100cm)
≤70dB
Emergency Stop Torque (N.m)
2 times the rated output torque
Allowable Radial Load
680N
Allowable Axial Load
340N
Rated Input Speed
1000rpm
Maximum Input Speed
2000rpm
Protection Level IP
IP65
Applied Motor
Nema 23 Stepper Motor
Packaging and delivery
Selling Units
Single item
Single package size
40X24X19 cm
Single gross weight
3.000 kg
Lead time
Product descriptions from the supplier
FREE shipping capped at £20
Minimum order quantity: 1 piece
£1263
*Taxes and import charges will be calculated at checkout
Variations
Select nowModel Number: 60PF-10 Ratio 10
60PF-10 Ratio 10
Rated Power
Depending on the motor
