Attributes
CNC Routermachine type
3000*5000Working Table Size(mm)
5number of axes
ATCNo. of Spindles
380V/220Vvoltage
1 Yearwarranty
cnc or not:CNC
place of origin:Shandong, China
Power (kW):15
weight (kg):3800
range of spindle speed(r.p.m):0 - 24000 rpm
positioning accuracy (mm):0.03 mm
travel (x axis)(mm):3000 mm
travel (y axis)(mm):5000 mm
repeatability (x/y/z) (mm):0.03 mm
Spindle Motor Power (kw):10
brand name:Blue Elephant
dimension(l*w*h):Other
key selling points:Multifunctional
machinery test report:Provided
video outgoing-inspection:Provided
core components:Motor, PLC
Model:ELECNC-3050
Inverter type:15KW
Reducer:Japan SHIMPO reducer
Tool magazine:Carousel type auto tool changer
Traveling speed:80m/min
Working speed:0-25m/min
Working air pressure:0.6MPa
Working voltage:380V 3PH 50HZ/ 60HZ
Control system:Syntec 610MA-E5
Lubrication system:Semi-auto lubrication system
