Attributes
CNC Routermachine type
1300×2500Working Table Size(mm)
3number of axes
ATCNo. of Spindles
380V/220Vvoltage
1 Yearwarranty
cnc or not:CNC
place of origin:Shandong, China
Power (kW):11
weight (kg):3000
range of spindle speed(r.p.m):0 - 24000 rpm
positioning accuracy (mm):0.03 mm
travel (x axis)(mm):1300 mm
travel (y axis)(mm):2500 mm
repeatability (x/y/z) (mm):0.03 mm
Spindle Motor Power (kw):4.5
brand name:Blue Elephant
dimension(l*w*h):Other
key selling points:Easy To Operate
machinery test report:Provided
video outgoing-inspection:Provided
core components:Motor, PLC
Model:ELECNC-1325
Linear guide:PMI Linear guide
Command language:G Code
Traveling speed:30m/min
Working speed:0-15m/min
Re-positioning accuracy:±0.05mm
Compatible software:Artcam, Aspire, etc
Working accuracy:±0.05mm
Controller box:Independent controller box
Working voltage:220V 1PH/3PH 50HZ/60HZ 380V 3PH 50HZ/ 60HZ
