Industrial 5 Axis CNC Router NC Studio/RichAuto/Syntec Control PLC Core ATC Motor 3D Mold Making Wood Carving Applications

No reviews yet
Complies with EU standards
£5,61535
1-4 sets
£4,86664
5-14 sets
£4,11793
≥15 sets
Select now

Working Table Size(mm)

2000×4000
1300×2500
2000×3000
1500×3000
1200×1200
1220×2400

model number

BCM-5Axis-CE-1325
BCM-5Axis-CE-1530
BCM-5Axis-CE-2040
BCM-5Axis-CE-2060

Power (kW)

9kW
Customization options
Customized logo (Min. order: 1 set)
Customized packaging (Min. order: 1 set)
Graphic customization (Min. order: 1 set)
+2 more options

Key attributes

machine type

CNC Router

number of axes

5

No. of Spindles

ATC

voltage

380 V, 240V, 400V, 1P/3P, 50HZ/60HZ

warranty

3 Years

key selling points

Competitive Price

At a glance

  • 9KW Air Cooling Spindle: The 9KW air cooling spindle ensures efficient and consistent cutting performance, even during extended use, which is crucial for high-volume production and maintaining tool life.

  • 5 Axis Movement: Five-axis movement allows for complex and precise 3D woodworking, enabling the machine to handle intricate designs and detailed cuts with high accuracy.

  • Yaskawa Servo Motor: The Japanese Yaskawa servo motor provides reliable and precise control over the machine's movements, ensuring smooth and accurate operation for high-quality results.

  • 1300x2500mm Working Area: A large working area of 1300x2500mm accommodates a wide range of materials and projects, making it versatile for various applications in furniture, signage, and precision cutting.

Shipping

Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.

Key attributes

machine type
CNC Router
number of axes
5
No. of Spindles
ATC
voltage
380 V, 240V, 400V, 1P/3P, 50HZ/60HZ
warranty
3 Years
key selling points
Competitive Price
core components
Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Engine, Gearbox
machinery test report
Provided
video outgoing-inspection
Provided
cnc or not
CNC
place of origin
Shandong, China
weight (kg)
2000
range of spindle speed(r.p.m)
6000 - 30000
positioning accuracy (mm)
0.01
travel (x axis)(mm)
1300
travel (y axis)(mm)
2500
repeatability (x/y/z) (mm)
0.01
Spindle Motor Power (kw)
9
brand name
BCAMCNC
dimension(l*w*h)
3500*2000*1550mm
Accessory Type
Dust collection, Scanner
Product name
5 Axis CNC Router
Application
FOAM MDF WOOD ACRYLIC ALUMINUM
Keywords
3d Wood Cutting Cnc Machine
Control system
Nc-studio/Mach3/DSP Control System
Spindle
9kw Air Cooling Spindle
Function
Foam 3d Models Making
Working area
1300x2500mm/1300x2800mm/Customized
Motor
Japan Yaskawa Servo Motor
Working table
Vacuum Table + Tslot
Transmission
Taiwan TBI Ball Screw
Name
5 Axis Cnc Engraving Machine
Spindle power
9.0kw ATC Air Cooling
Model
1325 Router Machine
Inverter
Delta Inverter
Table Surface
Vacuum Combined T-slot Table
Guide rail
Taiwan Hiwin Square Guide Rail
Software
Ucancam / ArtCam/TYPE3
Type
CNC Router Milling Machines
Working Voltage
AC220V/AC380/50HZ/60HZ
After-sales Service Provided
Service Machinery Overseas

Packaging and delivery

Selling Units
Single item
Single volume
0 cm³
Single gross weight
0.0 kg

Lead time

Customization options

Customized logo(+ from /Min. order: 1 set)
Customized packaging(+ from /Min. order: 1 set)
Graphic customization(+ from /Min. order: 1 set)
Voltage(+ from /Min. order: 1 set)
Working Table Size(mm)(+ from /Min. order: 1 set)
