Attributes
220v/380vvoltage
FANUCcnc control system
Medium Dutymachining capacity
2number of axes
Singleno. of spindles
12tool post stations
max. length of workpiece (mm):1400
key selling points:High-Accuracy
repeatability (x/y/z) (mm):±0.005
positioning accuracy (mm):±0.005
warranty:1 Year
type:Horizontal
machinery test report:Provided
video outgoing-inspection:Provided
max. weight of workpiece(kg):1000
travel (x axis)(mm):450
travel (z axis)(mm):2000
place of origin:Jiangsu, China
width of bed (mm):210
dimension(l*w*h):4000*2000*2100
brand name:Minnuo
model number:TCK50Y
weight:5100
range of spindle speed:0 - 3000 r.p.m
cutting torque:10
Product name:high-efficiency spindle lathe machine cutting tool
CNC Controller:Siemens 808DA,GSK,fanuc
CNC or Not:CNC Lathe Machine
Distance between centers(mm):1500
Repeatability (X/Y/Z) (mm):±0.005
spindle nose:A2-8
Z axis sfast moving speed(m/min):18
Cylindrical tool dimensions(mm):25*25
Total rated power:24KW
sleeve taper:MT5#
