Attributes
380 V, 220 VVoltage
2.2KWPower(W)
Aluminum alloy framesApplicable Material
Guangdong, ChinaPlace of Origin
Motor, Pneumatic System, Saw Blade, Guide Rail / Slider, Cylinder, Machine Bed Structure, Electrical ComponentsCore Components
200 kgWeight
Warranty:1 Year
Key Selling Points:High Productivity
Video outgoing-inspection:Provided
Machinery Test Report:Provided
Brand Name:ZLWM
Dimension(L*W*H):760x840x1140(mm)
Working Air Pressure:0.5-0.8 MPa
Total Power:2.2 kW
Spindle Power:2.2 kW
Saw Blade Speed:6000 rpm
Saw Blade Specification:305 * 25.4 * 3.0 * 120T
Sawing Angle:90° / 45° / 45° guard angle
Max Cutting Thickness:90 mm
Max Cutting Stroke:Max Cutting Stroke
Sawing Method:Cutting from front to back
Cutting Length Accuracy:±0.15 mm
Angle Accuracy:5-10
Equipped Aluminum Ruler (L*W*H):1500 * 35 * 45 mm (1 pc) / 350 * 35 * 45 mm (1 pc)
Saw Cutting Speed:0-10 m/min
Processing Method:Mold positioning
Operation Mode:Semi automatic
Machine Dimension (L*W*H):Approx 760 * 840 * 1140 mm
Total Weight:Approx 200 kg
Machine Operating Environment:Power cable: 1.5² 380V 50Hz
Ambient temperature (24h):5-40°C
Relative humidity:30-75 percent
Selling Units:Single item
Single gross weight:1800.000 kg
