Attributes
DieselPower Type
JIUHE/JHBrand Name
20 mMax. vertical conveying distance
17 mMax. horizontal conveying distance
50M³/HProductivity
Shandong, ChinaPlace of Origin
Warranty:1 Year
UNIQUE SELLING POINT:Fully hydraulic system
Core Components:Pressure Vessel, Motor, Bearing, Gear, Gearbox
Color:Optional
Weight:11800
Dimension(L*W*H):6900*2250*3000mm
Machinery Test Report:Provided
Video outgoing-inspection:Provided
Emission standard:China VI
Power:150kw
Wheelbase:3750mm
Max. Boom height:20m
Max. Placing radius:17m
System Working Pressure:32 Mpa
Hydraulic Cylinder Inner Dia.* Stroke:100mm*1000mm
Max. Theoretic pumping capacity:50M3
Concrete Cylinder Inner Dia.* Stroke:200*1000
Max. Allowable concrete size:30mm
