Attributes
DieselPower Type
JIUHE/JH/ODMBrand Name
25MMax. vertical conveying distance
22MMax. horizontal conveying distance
50M³/HProductivity
Shandong, ChinaPlace of Origin
Warranty:1 Year
UNIQUE SELLING POINT:Fully hydraulic system
Core Components:Pressure Vessel, Motor, Bearing, Gear, Gearbox
Weight:16000
Dimension(L*W*H):8840*2300*3433mm
Machinery Test Report:Provided
Video outgoing-inspection:Provided
Concrete placing radius(M):22
Concrete placing depth(M):13.8
Boom folding type:M-type
Working voltage(V):24
System working pressure(Mpa):31.5
Max.concrete outlet pressure(Mpa):7.1
Maximum loading height(MM):1450
Hopper capacity (M3):0.65
Max. Allowable aggregate size(MM):40
