Attributes
16200*3300*2600mmWorking Table Size(mm)
CNC Routermachine type
CNCcnc or not
Shandong, Chinaplace of origin
380V/220Vvoltage
11Power (kW)
weight (kg):3200
warranty:One year
range of spindle speed(r.p.m):0 - 24000 rpm
positioning accuracy (mm):0.03
number of axes:3
No. of Spindles:ATC
travel (x axis)(mm):1300
travel (y axis)(mm):2500
repeatability (x/y/z) (mm):0.03
Spindle Motor Power (kw):Other
brand name:Blue Elephant
dimension(l*w*h):Other
key selling points:Long Service Life
machinery test report:Provided
video outgoing-inspection:Provided
core components:Motor, Other
Model:ELECNC1325ATC with auto loading and unloading
Inverter type:11kw Delta
Spindle type:9kw ATC air cooling spindle, ISO30, ER32
Driling bank:Italy 5+4 vertical drills
Reducer:Japan SHIMPO reducer
Traveling speed:80m/min
Working speed:0-25m/min
Re-positioning accuracy:±0.03mm
Working air pressure:0.6MPa
Working voltage:380V/220V
Selling Units:Single item
