Outdoor Full Color LED Video Cabinet 5500 Brightness IP65 Waterproof Digital Signage Advertising SDK CMS Animation Retailer
No reviews yet
AISTAR TECHNOLOGY SDNBHD
MY1 yr on Alibaba.com
Response Time ≤ 1h
Attributes
LED cabinetspecification
OutdoorUsage environment
P3.906Pixel Pitch
5000~5500 Nitsbrightness
IP65ip rating
500*500mm, 500×1000 mmDimensions
application:Outdoor
aspect ratio:16:9, Other
Screen Type:LED Display Screen
warranty:2 Years
place of origin:Guangdong, China
Remote Device Management:No
use:LED video wall
model number:Aor 3.9 Lite
brand name:Aistartech
color:Full Color
Color Depth:14~16Bit
Content Management System:Yes
Contrast Ratio:≥15000:1
Control Method:Computer
Display Function:Animation
function:SDK
installation type:Hanging Stacking
lifespan (hours):10000
Material:Die Casting Aluminum
media available:Other
Mounting type:Hanging, Stacking
Operating Temperature:-40℃-80℃
Operation System:Windows
panel brand:Aistartech
Pixel Density:65536Pixel/Sqm
Pixels:3 mm
resolution:128X128
response time:≤5ms
supplier type:Original Manufacturer, ODM, OEM
Touch Screen:No Touch
view angle（h/v）:140°/ 120°
Voltage:100-110V/200-240V, 50-60Hz
Pixel Structure (SMD:1921
Module resolution (W*H:72*48
Module weight (kg):2
Box module composition (W*H):2*3
Box resolution (W*H:144*144
Box size (mm:500x500x72mm/500x1000x72mm
Box area (㎡):0.25/0.5
Regular weight (kg per box):24.5
Pixel density (points /㎡):65536Pixel/Sqm
IP rating:IP65/IP54
Gray scale level (bit:14~16
Color temperature (K:6500-9000
Uniformity of brightness:≥97%
Chromaticity uniformity:±0.003Cx, Cy
Maximum power consumption (W/㎡:550
Average power consumption (W/㎡:186
Power supply requirements:AC100~240V
Frame change frequency (Hz:50&60
Refresh rate (Hz:3840
LED lifespan (hrs):100,000
Key attributes
specification
LED cabinet
Usage environment
Outdoor
Pixel Pitch
P3.906
brightness
5000~5500 Nits
ip rating
IP65
Dimensions
500*500mm(19.69*19.69in), 500×1000 mm
resolution
128X128
Content Management System
Yes
Remote Device Management
No
Touch Screen
No Touch
Control Method
Computer
aspect ratio
16:9, Other
Operating Temperature
-40℃-80℃
Contrast Ratio
≥15000:1
Color Depth
14~16Bit
Mounting type
Hanging, Stacking
Voltage
100-110V/200-240V, 50-60Hz
Material
Die Casting Aluminum
warranty
2 Years
Operation System
Windows
function
SDK
Display Function
Animation
Screen Type
LED Display Screen
use
LED video wall
application
Outdoor
Pixels
3 mm
view angle（h/v）
140°/ 120°
Pixel Density
65536Pixel/Sqm
response time
≤5ms
media available
Other
supplier type
Original Manufacturer, ODM, OEM
place of origin
Guangdong, China
model number
Aor 3.9 Lite
brand name
Aistartech
color
Full Color
installation type
Hanging Stacking
lifespan (hours)
10000
panel brand
Aistartech
Pixel Structure (SMD
1921
Module resolution (W*H
72*48
Module weight (kg)
2
Box module composition (W*H)
2*3
Box resolution (W*H
144*144
Box size (mm
500x500x72mm/500x1000x72mm
Box area (㎡)
0.25/0.5
Regular weight (kg per box)
24.5
Pixel density (points /㎡)
65536Pixel/Sqm
IP rating
IP65/IP54
Gray scale level (bit
14~16
Color temperature (K
6500-9000
Uniformity of brightness
≥97%
Chromaticity uniformity
±0.003Cx, Cy
Maximum power consumption (W/㎡
550
Average power consumption (W/㎡
186
Power supply requirements
AC100~240V
Frame change frequency (Hz
50&60
Refresh rate (Hz
3840
LED lifespan (hrs)
100,000
Packaging and delivery
Selling Units
Single item
Lead time
Product descriptions from the supplier
1 - 399 pieces
£12143
400 - 1,599 pieces
£11685
>= 1,600 pieces
£11074
Variations
Select now屏幕尺寸
500x500x72mm(19.69x19.69x2.83in)
500x1000x72mm(19.69x39.37x2.83in)
Shipping
Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.
