Attributes
16:9, Otheraspect ratio
Outdoorapplication
4000~4500 Nitsbrightness
IP 65 / IP54ip rating
2.976mmPixels
-20°C To 50°COperating Temperature
warranty:2 Years
Screen Type:Led
function:SDK
Display Function:Animation
Content Management System:Yes
specification:LED cabinet
Remote Device Management:No
supplier type:Original Manufacturer, ODM, OEM
media available:Other
use:LED video wall
Pixel Density:112896Pixel/sqm
place of origin:Guangdong, China
model number:Aor2.9
brand name:Asitartech
color:Full Color
Color Depth:16-Bit
Contrast Ratio:50000:1
Control Method:Computer
Dimensions:500x500x72mm/500x1000x72mm
installation type:Hanging Stacking
Material:Die Casting Aluminum
Mounting type:Fixed To The Wall
panel brand:AistarTech
Pixel Pitch:P2.9
Size:1000mm X 1000mm
Usage environment:Outdoor
view angle（h/v）:140/140, 160°, 140°
Voltage:100-110 V / 200-240 50-60 Hz
LED:SMD1415
Pixel per Panel(WxH):168x168/ 168x336
Weight:7 Kg/Panel/11.5 Kg/Panel
Processing:14~16 bit
Refresh Rate:≥7680 Hz
Driving Type:1/21
Signal Transmission:<100 m(CAT5) 100m-500m (Multimode ) 500m-10km (Single mode)
Max Power Consumption:600w/Sq.m
Average Power Consumption:300w/Sq.m
Recommended Application:Rental
Humidity:10%-90% (operational) 10%-90% (storage)
