Attributes
ChinaPlace of Origin
SinetongBrand Name
PT10M-H5Model Number
0.15W(50℃)Rated Power
Carbon FilmTechnology
potentiometerProduct
Total Resistance:100Ω ~2MΩ
Total Resistance tolerance:100Ω~1MΩ ±20% (1MΩ~2MΩ ±30%)
Rated power:0.15W(50℃)
rotation of noise:≤47mV
Electrical Rotation angle:220°±20°
Max operating voltage:200VDC
Total rotation angle:235°±10°
Rotation torque:0.3-2.0Ncm
Stop torque:>5Ncm
Type:Rotary Potentiometer
Operating Temperature:Potentiometers
Max. Operating Voltage:200VDC
Resistance Tolerance:100Ω~1MΩ ±20% (1MΩ~2MΩ ±30%)
Resistance:100Ω ~2MΩ
