Attributes
1 Yearwarranty
500L/Hourproductivity
20weight (kg)
FiltrationProcessing Type
10 kWPower(W)
220 VVoltage
video outgoing-inspection:Provided
machinery test report:Provided
core components:Pressure Vessel, Hollow Fiber Membrane
place of origin:United States
brand name:WOBO
Dimension(L*W*H):Comes with optional specifications
Model:C-CM-10
Membrane Area (m²):10
Module Dimensions (L1xL2xD1, mm):1452x1030x205
Inlet/Outlet Port Size (D2, D3, mm):60 (same for all models)
Permeate Flow Rate (m³/h):0.8~2.5
Membrane Pore Size (nm):30, 50, 100 (optional)
Membrane Channel Diameter (mm):2~4 (same for all models)
Membrane Material & Sealing:a-Al2O3, ZrO2; Sealed by fluororubber, EPDM, FFKM, or epoxy resin
Module Housing Material:UPVC, SS, FRP (optional)
Filtration Type:Inside-out, dead-end filtration, partial cross-flow
Selling Units:Single item
