Purifit Alternative Domino Inkjet Printer Parts New Black Ink Pump MG 6 Month Warranty 0.5kg

No reviews yet
DOCOD PRECISION GROUP LIMITED
1 yr
HK

Attributes

Otherapplication
0.8MPapressure
OEM, ODM, OBMcustomized support
1 Yearwarranty
Chinaplace of origin
Electricpower source
structure:ink pump
model number:GQA175FSLD01
Applicable temperature:-40 to 105 degrees Celsius
Max Flow Rate:2.5L/min
Max Pressure:0.8MPa (preset value0.7MPa)
motor:Servo Motor, Brushless DC Motor, Stepper Motor
Material:Stainless Steel
Nominal Displacement:0.65ml/rev
Max. Flow Rate:.5L/min (water as medium)
Max. Pressure:0.8MPa
Viscosity Range:0.5-1500CP
Operating Speeds:500-4500rpm
Rated Voltage:24VDC
Rated Power:40W
Gear Material:Metal
Pump Body Material:SUS316L
Static Seal:PTFE (gaskets), EPDM (O-rings)
thread specifications:Standard configuration G1/8-28(customizable)
Compatible Drive:Brushless DC Motor, Stepper Motor, Servo Motor
Temperature resistance:-40 to 105 degrees Celsius
Shaft Material:Porcelain

Key attributes

application
Other
pressure
0.8MPa
customized support
OEM, ODM, OBM
warranty
1 Year
place of origin
China
power source
Electric
structure
ink pump
model number
GQA175FSLD01
Applicable temperature
-40 to 105 degrees Celsius
Max Flow Rate
2.5L/min
Max Pressure
0.8MPa (preset value0.7MPa)
motor
Servo Motor, Brushless DC Motor, Stepper Motor
Material
Stainless Steel
Nominal Displacement
0.65ml/rev
Max. Flow Rate
.5L/min (water as medium)
Max. Pressure
0.8MPa
Viscosity Range
0.5-1500CP
Operating Speeds
500-4500rpm
Rated Voltage
24VDC
Rated Power
40W
Gear Material
Metal
Pump Body Material
SUS316L
Static Seal
PTFE (gaskets), EPDM (O-rings)
thread specifications
Standard configuration G1/8-28(customizable)
Compatible Drive
Brushless DC Motor, Stepper Motor, Servo Motor
Temperature resistance
-40 to 105 degrees Celsius
Shaft Material
Porcelain

Packaging and delivery

Selling Units
Single item
Show more

Lead time

Product descriptions from the supplier

1 - 99 pieces
$28846
100 - 499 pieces
$23077
>= 500 pieces
$19231
