Attributes
Oxygen-free Tinned Copper WireConductor Material
XLPOInsulation Material
1.5KVRated Voltage
1*4.0 mm², 1*2.5 mm², 1*16.0 mm², 1*10.0 mm², 1*1.5 mm², 1*25.0 mm², 1*35.0 mm²Size
Guangdong, ChinaPlace of Origin
62930 IEC131 1x2.5 mm2Model Number
Brand Name:PNTECH
Application:Power Station
Jacket:XLPO
Type:solar cable
Product name:Solar Cable
Wire specification:1x2.5mm2
Rated voltage:AC:Uo/U=1.0/1.0KV DC:1.5KV
Voltage test on completed cable:AC:6.5KV DC:15KV,5min
Ambient Temperature:-40℃~+90℃
Max Temperature at conductor:+120℃
Service Life:25 years(-40℃~+90℃)
Cold bending test:EN60811-504
Damp Heat Test:EN60068-2-78
Weathering/UV-resistance:IEC 62930
Selling Units:Single item
