Attributes
5-YearWarranty(Year)
Guangdong, ChinaPlace of Origin
PV-12036DT-P1(DALI)/PV-24036DT-P1(DALI)Model Number
Pt POWERBrand Name
Led Lighting, Indoor LightingApplication
PlasticCase Material
Dimming:DALI 2 in 1 Dimmable
Dimming Mode:DALI & Push Dimmable
Efficiency:≥84%
Energy Transfer:AC-DC
Input Voltage:100-240VAC
Lighting solutions service:Lighting And Circuitry Design, Project Installation, Other
Output Current:1.5A/3A
Output Frequency:50~60 Hz
Output Power:36W
Output Type:Single
Product Weight（kg）:0.19
Topology:Ac-Dc Converter
Type:IP20 Non-waterproof, Switching
Type:Constant Voltage Led Lighting
OEM/ODM:Yes
IP Rate:IP20
Certification:CE/UKCA/SAA/RoHS
Size:264*30*18.5mm(L*W*H)
Working temperature:-25°C~+45°C
Feature:Flicker-free dimming 0-100%
Standby power consumption:<0.5W
DALI Standard:IEC62386
EMC Standard:EN55015,EN61000-3-2,EN61000-3-3
Safety standard:EN61347-1,EN61347-2-13
Other application:Class 1 2 3 LED Lighting
