Robot Motor OD60mm Torque Height 17.9mm 0.45NM Frameless Direct Drive BLDC Torque Medical Robotic Motor for Robot Joint Actuator
No reviews yet
Attributes
customContinuous Current(A)
IE 4Efficiency
3000Speed(RPM)
ChinaPlace of Origin
NOFrame
Panel MountMotor Mounting Type
Rated Power:141.5W
Model Number:U6017
Brand Name:other
Commutation:Brushless
Construction:Permanent Magnet
IP Rating:other
Protect Feature:Totally Enclosed
Speed Rpm:3 000 RPM
Torque:0.45Nm
Type:Brushless Motor
Usage:Boat, Car, Electric Bicycle, Fan, Home Appliance, Cosmetic Instrument, Smart Home, Semiconductor chip installation
Warranty:Other
OD(mm):60
Height(mm):17.9
Voltage(VDC):48
Rated torque (Nm):0.45
Max torque:1.3
Rate Speed:3000
Max Speed*1 (Rpm):4500
Rated Current(Arms):5
Instant Max Current (Arms):15
Rated Output(W):141.5
Key attributes
Continuous Current(A)
custom
Efficiency
IE 4
Speed(RPM)
3000
Place of Origin
China
Frame
NO
Motor Mounting Type
Panel Mount
Rated Power
141.5W
Model Number
U6017
Brand Name
other
Commutation
Brushless
Construction
Permanent Magnet
IP Rating
other
Protect Feature
Totally Enclosed
Speed Rpm
3 000 RPM
Torque
0.45Nm
Type
Brushless Motor
Usage
Boat, Car, Electric Bicycle, Fan, Home Appliance, Cosmetic Instrument, Smart Home, Semiconductor chip installation
Warranty
Other
OD(mm)
60
Height(mm)
17.9
Voltage(VDC)
48
Rated torque (Nm)
0.45
Max torque
1.3
Rate Speed
3000
Max Speed*1 (Rpm)
4500
Rated Current(Arms)
5
Instant Max Current (Arms)
15
Rated Output(W)
141.5
Packaging and delivery
Selling Units
Single item
Single package size
12X12X12 cm
Single gross weight
30.000 kg
Lead time
Product descriptions from the supplier
2 - 299 pieces
$190
>= 300 pieces
$72
Variations
Select nowRated voltage: /
/
Output Power: 141.5W
141.5W
Speed of Revolution
3000
Shipping
Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.
