Complies with EU standards
Attributes
CNC Routermachine type
1300×2500Working Table Size(mm)
3number of axes
ATCNo. of Spindles
AC380V/50HZvoltage
3 yearswarranty
cnc or not:CNC
place of origin:Shandong, China
Power (kW):9.5
weight (kg):2000
range of spindle speed(r.p.m):1 - 24000 rpm
positioning accuracy (mm):0.05
travel (x axis)(mm):1300
travel (y axis)(mm):2500
repeatability (x/y/z) (mm):0.05
Spindle Motor Power (kw):3kw
brand name:BCAMCNC
dimension(l*w*h):1300*2500*250mm
key selling points:Multifunctional
machinery test report:Provided
video outgoing-inspection:Provided
core components:Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Engine, Gearbox
Accessory Type:Dust collection
Table Surface:Vacuum table+Intergrated T-solt table clamping System
After-sales Service Provided:24 Hours Online Service + Local Service
Spindle Power:ES951 9.5kw Italy Air Cooling Spindle
Cutting thickness:According materials
Drive Motors:Japanese Yaskawa Servo Drive System
Operating System:Taiwan Syntec 6MB control system
Interface:USB
