Pneumatic Spring Loaded Pressure Safety Valve for Boiler Steam API 526 Compliant Flange Connection

Name: Pneumatic Spring Loaded Pressure Safety Valve for Boiler Steam API 526 Compliant Flange Connection
Brand: JACKWELL. INC
SKU: 1601668645761
Price: 4000 USD
Availability: InStock

No reviews yet

JACKWELL. INC

2 yrs

Attributes

FlangeConnection Type

6000 barMax. Operating Pressure

800°CMax. Operating Temperature

Gas/Oilmedia

12port size

Safetystructure

customized support:OEM

place of origin:Germany

application:Industries

power:Pneumatic

model number:API TYPE 526

brand name:LESER

warranty:1 Year

Applications:Oil & Gas/Chemical/Petrochemical/Energy/Technical Gases/Sugar Ethanol

Bellows Material (optional):INCONEL 625

Nominal Diameter at Inlet:DN 25 - DN 200 | 1" - 8"

Orifice:D - T

Actual Orifice Diameter d:14 - 161.5 mm | 0.551 - 6.36 in

Actual Orifice Area A:154 - 20485 mm² | 0.239 - 31.75 in²

Pressure:0.12 - 413.8 bar | 2 - 6000 psig

Flange Rating Inlet:CL150 - CL2500

Temperature (in accordance with DIN EN):-270 to 550 °C | -454 to 1022 °F

Load Type:Spring loaded

Key attributes

Connection Type

Flange

Max. Operating Pressure

6000 bar

Max. Operating Temperature

800°C

media

Gas/Oil

port size

structure

Safety

customized support

OEM

place of origin

Germany

application

Industries

power

Pneumatic

model number

API TYPE 526

brand name

LESER

warranty

1 Year

Applications

Oil & Gas/Chemical/Petrochemical/Energy/Technical Gases/Sugar Ethanol

Bellows Material (optional)

INCONEL 625

Nominal Diameter at Inlet

DN 25 - DN 200 | 1" - 8"

Orifice

D - T

Actual Orifice Diameter d

14 - 161.5 mm | 0.551 - 6.36 in

Actual Orifice Area A

154 - 20485 mm² | 0.239 - 31.75 in²

Pressure

0.12 - 413.8 bar | 2 - 6000 psig

Flange Rating Inlet

CL150 - CL2500

Temperature (in accordance with DIN EN)

-270 to 550 °C | -454 to 1022 °F

Load Type

Spring loaded

Packaging and delivery

Selling Units

Single item

Single package size

50X50X30 cm

Single gross weight

50.000 kg

Lead time

Product descriptions from the supplier

1 - 9 sets

£6,63843

10 - 19 sets

£5,90083

>= 20 sets

£2,95042

Variations

Select now

Shipping

Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.

Alibaba.com order protection

Secure payments

Every payment you make on Alibaba.com is secured with strict SSL encryption and PCI DSS data protection protocols

Money-back protection

Claim a refund if your order doesn't ship, is missing, or arrives with product issues

Quantity (sets)	1 - 5	> 5
Lead time (business days)	90	To be negotiated
