Attributes
±(0.01% + 1)Accuracy Class
0.001mA~10AMeasuring Current Range
0.01mV~1000VMeasuring Voltage Range
DC Current, AC Voltage, Frequency, Temperature, DC Voltage, Capacitance, Continuity, Diode, Resistance, AC Current, Duty Cycle, Low Input ImpedanceParameters Measured
Guangdong, ChinaPlace of Origin
TA805AModel Number
Brand Name:TASI
Application:Industrial Use, Household Use
Digits Displayed:4 Digits
Dimensions:153*81*27mm
Feature:Standard
Low Battery Indicator:Yes
Material:Plastic, ABS, PVC
Max. AC Current:10A
Max. AC Voltage:750 V
Max. DC Current:10A
Max. DC Voltage:600 V
Measuring Capacitance Range:0.1nF~100,000uF
Measuring Inductance Range:NA
Measuring Resistance Range:0.1Ω~100MΩ
Operating Temperature:0-40℃
Model:TA805A
Range:Auto Identification / Manual
DC voltage:0.01mV~1000V±(0.5%+8)
AC voltage:0.01mV~750V±(0.8%+5)
AC/DC current:0.001mA~10A±(1%+2)
Resistance:0.1Ω~100MΩ±(0.8%+3)
Frequency:1Hz~10MHz(1.0%+5)
Power:3.7V 1000mAH lithium battery (wireless charging)
Size:153*81*27mm
Weight:235g ( battery not included)
