Attributes
Generalapplication
Basemedia
DN300-DN400Port Size
Controlstructure
OEMcustomized support
Taiwan, Chinaplace of origin
power:Electric
model number:UM-8 UM-11
brand name:MIT-UNID-CNS
temperature of media:Normal Temperature
warranty:1 years
Voltage:AC110V. AC220V. DC24V. DC12V. AC380V. AC440V (50/60 Hz)
Power (AC110V.AC220V):100W
Speed 90 sec 60Hz:37 secs. 52 secs. 65 secs
The Size of Value:DN300-DN400
Torque 5% kgf-cm2 110V:11038-15000 kgf-cm2
Torque 5% kgf-cm2 220V:9296-14500 kgf-cm2
Non-load current consumption:0.6A - 1.2A
Type:BALL VALVES
Product name:Electric Actuator
Connection:ISO5211
