Attributes
Inductor KitModel Number
Inductor Surface MountType
SQ-Tech / OEM Branding AvailableBrand Name
Smartphones, WiFi6 Routers, IoT Devices, RF ModuleApplication
0.25W ~ 1WRated Power
SMT ReflowMounting Type
Place of Origin:China
D/C:2024+ (In Stock)
Brand:ChipNova / OEM Branding
Supplier Type:Bulk & Custom Tunable
Cross Reference:MLG1005S CLF1005
Tolerance:±5%
Operating Temperature:55°C ~ +150°C
Package Type:0402(1.0x0.5mm) to 1210(3.2x2.5mm)
Resistance Tolerance:±2%
Temperature Coefficient:50ppm/°C
Resistance:10Ω~1kΩ@1GHz
Media Available:AEC-Q200 Grade 1
Frequency - Self Resonant:10MHz ~ 3GHz
Features:Ultra High Q (>100), Low ESR
Height - Seated (max):12mm ~ 35mm
Function:EMI/RFI Suppression, Ground Loop Elimination
Inductance:1mH ~ 50mH (Dual Symmetric)
Q @ Freq:50 @ 1MHz
Package / Case:2012 2014 2615 2617
Size / Dimension:1.0x0.5mm ~ 3.2x2.5mm
Heigh:0.5mm ~ 2mm
Number of Coils:Parallel/Series (Customizable)
Inductance - Connected In Parallel:10A ~ 50A
Inductance - Connected In Series:2X Rated
Current Rating - Parallel:3A ~ 10A
Current Saturation - Parallel:4.5A ~ 15A
DC Resistance (DCR) - Parallel:0.05Ω ~ 0.3Ω
DC Resistance (DCR) - Series:0.02Ω ~ 1.0Ω
Shielding:Military-Grade Epoxy Encapsulation
Material - Core:Nanocrystalline
Current Rating (amps):As per Datasheet
DC Resistance (DCR):Optimized for High Efficiency
