Attributes
380Vvoltage
KNDcnc control system
Heavy Dutymachining capacity
2number of axes
Singleno. of spindles
12tool post stations
max. length of workpiece (mm):500
key selling points:High-Accuracy
repeatability (x/y/z) (mm):±0.004
positioning accuracy (mm):±0.008
warranty:1 years
type:Horizontal
machinery test report:Provided
video outgoing-inspection:Provided
max. weight of workpiece(kg):500
travel (x axis)(mm):280
travel (z axis)(mm):550
place of origin:Shandong, China
width of bed (mm):35 mm
dimension(l*w*h):2790x1900x1850
brand name:Rowdai
model number:TCK56Y
weight:4500
range of spindle speed:50 - 4500 r.p.m
cutting torque:144
Tailstock travel:450mm
Tailstock sleeve travel:100mm
Tailstock spindle taper hole taper:5mohs
Outer circle knife:25x25
Boring bar diameter:40/32/25/20mm
Standard Cutting Diameter:240mm
Spindle end type and code:A2-6
Maximum passing bar diameter:50mm
Maximum turning diameter:360mm
Standard Tool Holder Form:Horizontal 8 position hydraulic
