Attributes
standardMounting Type
LV-N11NModel Number
originalBrand Name
Ray SensorUsage
originalDescription
PHOTODIODEType
Place of Origin:Japan
Theory:Optical sensor
Output:Switching Transducer
Power voltage:24 VDC (operating voltage 10 to 30 VDC (with ripple))
Power consumption:830 mW or less
Case material:Polycarbonate
Shock resistance:500 m/s2, 3 times in each of the X, Y, and Z directions
Output selection:LIGHT-ON/DARK-ON (switch-selectable)
Timer function:Timer OFF/OFF-delay timer/ON-delay timer/One-shot timer
Relative humidity:35 to 85 % RH (No condensation)
Ambient temperature:-20 to +55 °C -4 to +131 °F (No freezing)*3
Vibration resistance:10 to 55 Hz, Double amplitude 1.5 mm 0.06""
Selling Units:Single item
